Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Vandsec
  • Model Number: VW-ADB20CD
  • Type: Digital Camera
  • Style: Bullet Camera
  • Sensor: CCD
  • Technology: Infrared
  • Special Features: Waterproof / Weatherproof
  • Lens: Board Lens 3.6mm
  • IR LED: F5X36pcs
  • IR Range: 30M
  • Support: IR-CUT, 2D/3D DNR, OSD
  • Size: 175mm x 69mm x 55mm
  • Weight: 900g

Packaging & Delivery

Packaging Details CVI Bullet Camera: 1 set
Delivery Time 3-5 work days



Product Description
Features:
        Waterproof IR Bullet Camera
        SONY/SHARP/CMOS Color CCD
        IR LED: F5X36pcs, IR Range: 30M
        Lens: Board Lens 3.6mm
        Water resistance: IP67
        Built-in Bracket
        Size: 175mm x 69mm x 55mm



Model ID:VW-ADB10CDVW-ADB20CD
Description:Waterproof IR Bullet Camera ;IR LED: F5X36pcs, IR Range: 30M
TV System:NTSC / PAL
Chipset Solution:1/3" DH9801+PO3100 1.0 Mega 720P CMOS Sensor1/3" DH9801+1042 2.0 Mega 1080P CMOS Sensor
Horizontal resolution: 720P 1080P
Effective Pixels:1280(H)×720(V)1920(H)×1080(V)
Minimum Illumination0.001Lux
Lens:Lens: Board Lens 3.6mm
Sync,System:Internal Synchronization
Scanning System: 2:1 Interface
Shutter Speed:1/60~1/100,000sec (N), 1/50~1/100,000sec (P)
S/N Ratio:≥ 58dB
DWDR:YES
Noise Reduction:3D-NR
Power Source:DC12V ±10%
Consumption<5W
Operating Enviroment:-20℃~60℃ / 10% ~ 95%RH
Working Humidity:≤90%
Size(mm):175mm x 69mm x 55mm
Weight(kg):0.9 kg
Packaging & Shipping

  We customize the package of the surveillance Camera for our clients:



 Surveillance Camera  shipping condition:



Express:


1. DHL is our first choice to dispatch goods. We have long relationship with Hong Kong DHL. Good price, good service. You will receive goods usually 4-5 days.


2. TNT is very economy by some European countries, usually TNT Economy is the cheapest way, you will receive goods in one week.


3. UPS is good choice for some of Asia & Europ countries. You will receive the goods around 4-5 days.


4. Fedex is a better way for some island countries. Fedex Economy also accepted. You will receive the goods around 4-7 days.


5. EMS usually for some countries hard to do customs clearance, such as Ukraine or Russia, you do not need pay tax. But, EMS only for small package.


Forwarder:


1. We have our own forwarder by air and by Sea for your convenience, we will quotation a competitive price to you.


2. If you have your own forwarder, we are happy to assistant your forwarder shipping goods.





Our Services

Ⅰ. ODM Service

  1. Label Printing:

  Please send us your SKU number or your Model ID, we will print label and double check with you before goods dispatch.



  2. Manual Printing:

  Please send us your modified manual after your payment, we will print manual and double check with you before goods dispatch.



  3. Logo Printing:

  Your order over 50PCS total we can free print your logo, or will add $20 for silk print fee.

  Please send us .JPG format Logo within 2 colours, we will help you print on products and box, double check with you before goods dispatch.



Ⅱ. OEM Service

  1. Label Printing:

  Please send us your SKU number or your Model ID, we will print label and double check with you before goods dispatch.



  2. Manual Printing:

  Please send us your modified manual after your payment, we will print manual and double check with you before goods dispatch.



  3. Logo Printing:

  Please send us .JPG format Logo within 3 colours, we will help you print on products and box, double check with you before goods dispatch.



  4. Box:

  Please send us your designed box based on our box demision and graph paper, we will send our box demision and graph paper first.







Company Information

As a high-tech enterprise, we are engaged in the R&D, manufacturing, and exporting of surveillance products. We focus on high-end CCTV Cameras, IP Cameras, DVRs, NVR, HD-SDI, HD-CVI Products and CCTV relatives, Vandsec always dedicated to the World’s safety market to create a better life

Established in Aug 2008, as a specialized manufacturer, Vandsec developed more than 200 different models of CCTV Products. With many years’ experience in exporting CCTV products, Vandsec products have been accepted by customers in over 150 countries, especially in Europe , USA and South America.



Trade shows



FAQ



1.DVR Card problem;
(1). Check the BNC connector of the DVR channels, if the image also have the image interference., it must be the DVR Card problem.
(2). DVR ground wire do not connect it well. Check the gournd wire if not , add it and restart the DVR without outage.

2.DVR single channel or few channel has image interference, flicking and a line in the middle of the image.
(1). Check the Security camera is working well;
(2). Check th BNC is good one;
(3). Check the video line.

3. PTZ Camera or High speed dome can not control it;
(1). Check DVR RS-485 port is working well;
(2). Check the Voltage of RS-485 beside the Zoom modules and PTZ;
(3). Separate testing. Check each channel conncect to DVR, and find the one which can not control it;
(4). Check the decoder or hardware of ptz camera;
(5). Address, baud rate, and protocol.

4.Box camera, all in one camera no video image;
AC220 Voltage is regular;
Power supply output and input;
RS-485 or BNC Connector is right and well.

5.Black screen for monitor;
AC 220V voltage is regular.
Check the monitor on your computers.

6.DVR keyboard can not be controlled;
(1). DVR DC 12V is ok;
(2). Electrical current is OK.

7.DVR has Alarm noise.
(1). HDD has problems or fault;
(2). Video loss;
(3). Alarm signal has been triggered.
